Brushroll Motor for Shark Lift-Away NV601 NV680 Cleaner Head 13 Cog D4275K
by SPARES2GO
Sold out
Current price
£31.49
**Free UK Delivery (1-2 Days)**
Cleaner Head Brushroll Motor D4275K Type for Shark Vacuum Cleaners
Brand‑new, premium quality compatible replacement cleaner head brushroll motor for Shark vacuum cleaners.
This replacement D4275K brushroll drive motor is designed to restore full cleaning performance to your vacuum cleaner. Located inside the cleaner head, this motor powers the rotating brush bar via a 13‑tooth cog gear and fan impeller system, delivering the agitation required for deep carpet cleaning.
Over time, the original motor can suffer from bearing wear, brush wear, or thermal fatigue, leading to reduced torque, grinding noises, or complete brushroll failure. Replacing the motor with a correct‑spec D4275K unit ensures proper alignment, correct RPM, and reliable long‑term operation.
This is a brushed DC permanent magnet motor rated for 18,000–22,000 RPM, featuring an integrated thermal cut‑off protector and a precise 13‑tooth cog for accurate engagement with the transmission pulley system. Designed for 220–240V UK/EU/AUS models, it is a direct compatible replacement for machines originally fitted with a D4275K motor
Specification:
220–240V (UK / EU / AUS models only)
Output shaft fitted with 13‑tooth cog gear
Dimensions: Full Length: 100m (Approx'), Length (Inner) 75mm (Approx'), Full Width: 68mm (Approx'), Depth: 40mm Approx'
How to locate the D4275K code: Remove the floorhead from the vacuum body, turn the cleaner head upside down so the brushrolls are facing upward. Remove the brushroll and the small plastic end caps (if fitted), Look inside the cavity behind the brushroll — the motor sits in a recessed housing, the code D4275K is printed directly on the metal motor casing, usually in black ink or laser‑etched lettering.
Fits Models:
FOR SHARK
Lift-Away NV600 Series including: NV601UK, NV601UKT, NV602UKT
Lift-Away NV680 Series including: NV680UK, NV680UKT, NV681UK, NV681UKT
**Will only fit if your existing brush bar motor has the code D4275K printed on it. Please be sure to meter test the old motor and PCB to confirm diagnosis before ordering.**
***Please note: all dimensions indicated in this ad are approximate and may vary slightly from indicated measurements. They are included as a guide to assist you in selecting the right part for your machine***
This product is designed to be compatible with the specified brand(s) and is not the original part. The name, model names and any part numbers of the original manufacturer(s) have been used for reference purposes only and are in no way associated with the original parts or manufacturer.
