Hotpoint Dual Heating Element Grill Oven 2600w C00573030 DD2 DD4 DU2 DU4
by Hotpoint
Current price
£34.79
**Free UK Delivery (1-2 Days)**
Availability: Only 2 left in stock
Genuine Dual Grill Heating Element for Hotpoint Oven (2600w)
Brand new, genuine original replacement dual heating grill element for Hotpoint oven. Located in the roof of the oven cavity, it provides intense top-down heat for grilling, browning, crisping and cooking foods. This dual-circuit element consists of two 1300W sections, producing a total output of 2600W. It allows even heat distribution across the grill area and restores full grilling performance when the original element has failed.
Specification:
Part Numbers: C00573030, 488000573030
Type: Dual Grill Element
Power: 2600w (1300w + 1300w)
Height: 350mm (Approx.')
Width: 345mm (Approx.')
Crossbar: 460mm (Approx.')
Bracket Length: 135mm (Approx.')
Bracket Width: 26mm (Approx.')
Tags: 32mm (Approx.')
Distance between hole centres: 75mm (Approx.')
When to Replace:
Grill not heating at all
One side of the grill not working
Uneven browning of food
Grill taking much longer to heat
Burning smell from the element
Visible blistering, cracking or burn marks
Electric trips when grill is switched on
Element glows in one section only
The element shows visible damage.
How to Fit:
Switch off the cooker at the mains.
Allow appliance to cool completely.
Remove the oven shelves.
Locate the grill element fixed to the oven roof.
Remove the retaining screws securing the element.
Carefully lower the element towards you.
Make a note of the wiring positions or take a photograph.
Disconnect the electrical terminals.
Connect the wires to the new element.
Reposition the element against the oven roof.
Refit all fixing screws.
Restore power and test grill operation.
Fits Models:
HOTPOINT
DD2 540 BL, DD2 540 IX, DD2 540 WH, DD2 544 C IX, DD2 844 C BL, DD2 844 C IX, DD2540IX, DD4 541 IX, DD4 544 J IX, DD4541IX, DKD5 841 J C IX, DKU5 541 J C IX, DU2 540 BL, DU2 540 IX, DU2 540 WH, DU2540IX, DU4 541 IX, DU4 541 J C IX, DU4 841 J C IX, DU4541IX
***Please note: all dimensions indicated in this ad are approximate and may vary slightly from indicated measurements. They are included as a guide to assist you in selecting the right part for your machine***
