Leisure Dishwasher Drain Pump PBL 9941 9945 9946 9951 9960 9961 9962 1748200100
by Leisure
Sold out
Current price
£26.99
**Free UK Delivery (1-2 Days)**
Genuine Leisure Dishwasher Drain Pump
Brand new, genuine original replacement drain pump for Leisure dishwasher.
Designed to efficiently remove dirty water from the dishwasher base at the end of each wash cycle, this pump ensures correct drainage through the outlet hose and prevents water pooling, error codes, and cycle interruptions.
The pump features a rear electrical connection, paired contacts, and a 3‑latch mounting system, making installation straightforward for most integrated and freestanding dishwashers. A built‑in thermal protector prevents overheating and extends motor life.
Specification:
Equivalent Part Numbers: 1748200100, 1740300200, 1740300100, 1740300300, 32X2769
Type: Arçelik SPD180230E31P‑01
Power: 25W
Voltage: 220–240V AC
Frequency: 50Hz
Current: 0.20–0.25A
Thermal Protection: Yes
Connection Type: Rear, two tag/blade terminals
Mounting: 3‑latch housing
When to Replace:
The drain pump removes wastewater from the dishwasher sump and pushes it through the drain hose. When the pump fails, you may experience:
Water left in the bottom of the dishwasher
Dishwasher stopping mid‑cycle
Error codes (drain faults)
Humming noise but no water movement
Flooding or leaks due to backflow
Replacing the pump resolves these issues and restores normal wash performance.
Fits models:
LEISURE
DI54280, DWLT48, DWLT68, PB9990FS, PBL 9941 SYA, PBL 9945 FTA, PBL 9946 FTA, PBL 9951 XYA, PBL 9960 YA, PBL 9961 YA, PBL 9962 SYA, PBL 9963 FTA, PBL 9980 FTA, PBL 9982 FTA, PBL 9990 FS, PBL 9991 FS, PDU34390
***Please note: all dimensions indicated in this ad are approximate and may vary slightly from indicated measurements. They are included as a guide to assist you in selecting the right part for your machine***
