Matsui Damper Shock Absorber Anti‑Vibration Leg Washing Machine M100WM09 M510WM13E
by Matsui
Sold out
Current price
£11.79
**Free UK Delivery (1-2 Days)**
Genuine Damper Shock Absorber Anti‑Vibration Leg for Matsui Washing Machine
Brand new, genuine original replacement damper shock absorber leg for Matsui washing machine. This damper stabilises the washing‑machine drum during wash/spin cycles, reducing vibration, noise, and internal wear.
Specification:
Equivalent 12938100000466, 302502300005, 302502300062
Colour: Black / Silver
MIN Length: 190mm (Approx')
MAX Length: 290mm (Approx')
Eyelet Hole Inner Diameter: 11mm (Approx')
When to Replace:
Excessive vibration during wash or spin
Drum banging against the cabinet
Machine walking / moving across the floor
Loud knocking or thudding noises
Loose or wobbly drum when pushed by hand
Visible oil leakage from the damper
Damper rod moves too freely (no resistance)
Uneven spin cycles or imbalance errors
One damper worn more than the other
How to Fit:
Disconnect & Access:
Unplug the appliance, Remove the front lower panel or rear panel, Locate the two dampers at the bottom of the drum
Remove Old Damper:
Support the drum with one hand, Remove the chassis bolt/pin from the lower eyelet, Remove the tub bolt/pin from the upper eyelet, Slide the old damper out
Fit the New Damper:
Align the metal rod end to the tub bracket, Insert the tub bolt/pin and secure, Align the plastic body end to the chassis rail, Insert the chassis bolt/pin and secure, Ensure the damper sits at the correct angle (20–30°)
Reassemble & Test:
Refit the access panel, Run a rinse/spin test, Check for vibration, noise, or movement, Drum should feel firm and stable
Fits Models:
MATSUI
M100WM09, M510WM13E
***Please note: all dimensions indicated in this ad are approximate and may vary slightly from indicated measurements. They are included as a guide to assist you in selecting the right part for your machine***
